Digital type - Copper thickness Gauge

Product Description

Technical Parameters
Measuring Range                              F-type probe size: 0 ~ 3000μm
Error                                              ± 2μm or ± 2 ~ 4%
The minimum radius of curvature        5mm (convex); 25mm (concave)
Minimum measuring area                  φ20mm
Minimum base thickness                   0.5mm (F); 50μm (N)
Showing                                        4-digit display, backlight optional
Units of measurement                    um-mils optional
Calibration methods                        Standard, one point, two points
Statistics data                              Standard, standard deviation S, readings numbers n (maximum 9,999), maximum value max, minimum value min (not suitable for Type B)
Interface                                      RS232 (not suitable for Type B)
Power supply                                2 pieces 5th battery batteries
Instrument Size                            64x115x25mm
Probe size                                  φ15x62mm
